Martin D-17 Acoustic Guitar

Body & Construction

• Body Size: Dreadnought, 14-fret design

• Top Material & Finish: Mahogany, satin

• Back & Sides Material & Finish: Mahogany, satin

• Neck Joint: Dovetail

• Scale Length: 25.4″

• Bracing Pattern: Forward-shifted X-brace

  • Brace Material: Spruce

  • Brace Shape: GE-scalloped

  • Brace Size: 5⁄16″

• Binding: None

Top Appointments

• Color: Dark mahogany

• Rosette: Multi-stripe

• Pickguard: Faux tortoise (no inlay)

• Top Detail/Inlay: None

Bridge & Hardware

• Bridge Style: GE modern belly, drop-in saddle (ebony)

  • String Spacing: 2 5⁄32″

  • Saddle: Compensated bone, 16″ radius

• Bridge Pins: Bone (no dot inlays)

Neck & Fingerboard

• Neck Material & Finish: Select hardwood, satin (dark mahogany)

• Shape & Taper: GE modified low-oval, high-performance taper

• Join: 14th-fret dovetail

• Nut Width: 1 ¾″

• Fingerboard Material: Ebony

• Width @ 12th Fret: 2 1⁄8″

• Frets: 20 total

• Inlays: GE diamond & square short (abalone)

• Binding: None

• Side Dots: White

Headstock

• Shape: Solid with square-taper silhouette

• Headplate: East Indian rosewood, script “Old Style” overlay

• Nut Material: Bone

• Tuners: Nickel open-gear

• Knob: Butterbean

• Binding/Detail: None

Electronics

• None

Miscellaneous

• Case: Hardshell

•
